Fully Automatic Bottle Labeling Machine
Fully automatic bottle labeling machine
The Fully Automatic Dual-Side Labeling Machine is a self-adhesive labeling solution engineered for small to medium-scale breweries and beverage production lines. Designed specifically for beer and soda bottles, it applies labels to both sides simultaneously with precision and efficiency. Built with a stainless steel frame, PLC touchscreen control, and servo-driven technology, this machine delivers professional labeling quality for round, square, and flat containers without requiring specialized operators.
Technical Parameters
| Parameter | Specification |
|---|---|
| Model | Fully Automatic Dual-Side Labeler |
| Labeling Speed | 40–150 bottles/min (adjustable) |
| Labeling Accuracy | ±1 mm |
| Bottle Size Range | Length: 40–400mm; Width: 40–200mm; Height: 0.2–150mm |
| Label Height Range | 10–200mm |
| Label Width Range | 16–400mm |
| Label Roll Inner Diameter | Ø76mm |
| Label Roll Outer Diameter | ≤300mm |
| Control System | PLC + Touchscreen Interface |
| Voltage | 220V/50Hz (380V optional) |
| Power | 1,100–1,600W |
| Machine Dimensions (L×W×H) | 1,930×1,120×1,340mm to 3,000×1,450×1,600mm |
| Weight | 180–450kg |
| Frame Material | 304 Stainless Steel + Aluminum Alloy |
| Applicable Bottle Types | Round, square, flat bottles |
| Label Types | Self-adhesive, transparent/opaque, paper, film, electronic supervision codes |
| Optional Add-ons | Ribbon coder (date/batch printing) |
Product Features
High Precision & Quality
Achieve ±1mm labeling accuracy with servo-controlled dispensing heads and intelligent photoelectric tracking. The 8-dimensional adjustable labeling head (X-Y-Z + tilt) ensures perfect label placement on any bottle shape, eliminating wrinkles and bubbles.
Cost-Effective for Small Factories
Industrial-grade performance at a small-business-friendly price point. Increase production efficiency without massive capital investment-reducing labor costs and minimizing label waste through automatic detection and correction functions.
User-Friendly Operation
PLC touchscreen interface with multi-language support, automatic label length learning, and memory for multiple labeling parameters. Quick changeover between different bottle types in minutes, not hours-no special training required.
Versatile Application
Handles round, flat, and square bottles for beer, soda, water, juice, and other beverages. Works as a standalone unit or integrates seamlessly into existing production lines. Optional ribbon coder prints batch numbers and expiration dates inline.
Cooperation Process
Inquiry – Submit your requirements (bottle size, label specs, production volume)
Consultation – Our engineers recommend the optimal configuration
Quotation – Receive detailed proposal with pricing and lead time
Order Confirmation – Sign contract, arrange payment
Production – Manufacturing and quality control inspection
Shipping – Secure wooden case packaging, global shipping via FOB/CIF/EXW
Installation & Training – Video guidance or on-site support available
After-Sales Support – 1-year warranty, online technical support, spare parts supply
why choose us
Proven Performance – Reliable servo-driven system with thousands of units operating worldwide
Complete Support – Video technical support, online assistance, installation guidance, and operator training included
Customization Available – Tailored solutions for your specific bottle sizes, label types, and production requirements
FAQ
Q1: What types of bottles can this machine handle?
The machine labels round, square, and flat bottles used for beer, soda, juice, water, and other beverages. It accommodates bottles from 40mm to 400mm in length and up to 200mm in width.
Q2: What label materials are compatible?
Self-adhesive labels including paper, plastic film, transparent labels, hot-stamping labels, and electronic supervision codes.
Q3: How accurate is the labeling?
The machine achieves ±1mm accuracy (excluding product and label errors), ensuring professional, consistent results.
Q4: Is the machine difficult to operate?
No. The PLC touchscreen interface is intuitive with automatic label learning. Multiple label parameter sets can be saved for quick changeover between products.
Q5: What maintenance is required?
Regular cleaning of sensors and mechanisms with non-corrosive solutions, periodic lubrication, and inspection of drive components. Full maintenance guide provided with purchase.
Contact us today for a customized solution for your beverage production line!
