Vertical Pneumatic Paste Filling Machine
Vertical Pneumatic Paste Filling Machine
Vertical Pneumatic Paste Filling Machine features a vertical integrated frame structure with compact layout and stable mechanical operation. The whole machine consists of pneumatic control system, quantitative piston cylinder, material hopper, anti-drip filling nozzle, height adjustable workbench and manual foot switch. All core material contact components are made of high-quality stainless steel, which is corrosion resistant, easy to disassemble and fully washable, meeting industrial hygiene standards for food, cosmetic and pharmaceutical production.
The machine adopts fixed piston volumetric filling principle. By adjusting the piston stroke length, operators can accurately control each filling volume. The pneumatic driving system provides stable and balanced power output, ensuring uniform feeding speed and consistent filling effect for high-viscosity pastes. Equipped with precision anti-drip nozzles, the equipment effectively prevents paste overflow, wire drawing and residual dripping during filling pause, keeping containers and work surfaces clean and reducing material waste.
Technical Parameter Table
|
Technical Parameters |
Unit |
Specification Range |
|---|---|---|
|
Filling Volume |
ml |
5-1000 customizable |
|
Filling Accuracy |
% |
±1 to ±2 |
|
Production Capacity |
bottles/h |
300-1200 depends on volume and material viscosity |
|
Applicable Material |
- |
Paste, cream, gel, slurry, semi-fluid, high viscosity materials |
|
Working Air Pressure |
MPa |
0.4-0.6 |
|
Filling Nozzle |
- |
Single nozzle standard, dual nozzle optional |
|
Operation Mode |
- |
Foot switch manual / automatic continuous filling |
|
Material Contact Material |
- |
304 Stainless Steel |
|
Adjustable Workbench Height |
mm |
0-200 |
|
Hopper Capacity |
L |
20 / 30 customizable |
|
Dimension (L×W×H) |
mm |
600×450×1300 standard |
|
Net Weight |
kg |
85 |
Core Advantages
Pure Pneumatic Safe Operation
The whole machine adopts full pneumatic drive without electric components in working areas. It avoids electric leakage, static electricity and spark risks, ensuring safe production for flammable, explosive and dust-prone workshops, which greatly improves factory safety standards.
Stable Filling Precision & Low Waste
Volumetric piston filling structure provides stable and repeatable filling volume. The precision control stroke effectively reduces filling errors, avoids excessive filling and material overflow, and lowers raw material loss rates during mass production.
Strong Viscosity Adaptability
Vertical integrated layout occupies small floor space, suitable for compact workshops and small production rooms. The vertical feeding design makes material circulation smoother and reduces residual dead corners inside the equipment.
Easy Cleaning & Maintenance
Stainless steel material contact parts support full disassembly and water washing. The simple mechanical structure has fewer wearing parts, low daily maintenance difficulty and low operating cost, greatly reducing factory labor and maintenance expenses.
why choose us
High Cost Performance & Fast ROI: Compared with expensive fully automatic filling production lines, this vertical pneumatic paste filling machine has low purchase cost, low energy consumption and stable output. It quickly replaces manual work and brings obvious cost-saving benefits for small and medium manufacturers.
Wide Industry Compatibility: Applicable for cosmetics, daily chemicals, food, pharmaceuticals, industrial adhesives and grease products. One machine meets multiple industry production standards and helps customers expand product ranges without additional equipment investment.
High Hygiene Standard Compliance: Food-grade stainless steel structure supports high-standard cleaning procedures, complying with GMP, CE and international hygiene requirements. It helps customers pass factory audits and product certification smoothly.
