Bag Filling And Sealing Packaging Machine
Bag Filling and Sealing Machine
Looking for a professional, all-in-one solution to automate bag filling and sealing processes-for everything from granular, powdered, and liquid products to solid, paste, and mixed materials-our Bag Filling and Sealing Packaging Machine is the ultimate choice to optimize your production line. As a core equipment in modern packaging workflows, this machine integrates automatic bag feeding, precise filling, secure sealing, date coding, and finished product output into a seamless, efficient process, replacing inefficient manual or semi-automatic packaging methods that are prone to errors, waste, and high labor costs. Unlike generic packaging machines, our Bag Filling and Sealing Packaging Machine is engineered to handle diverse bag types and material characteristics, ensuring consistent, leak-proof, and aesthetically pleasing packaging that complies with global industry standards (CE, FDA, GMP, JB/T 7549.4-94). Whether you're a small-batch producer or a large-scale industrial enterprise, this machine delivers reliable performance to boost productivity, reduce operational costs, and enhance product quality, making it a top search choice for businesses worldwide seeking bag filling and sealing solutions.
Technical Parameter Table
|
Parameter Name |
Semi-Automatic Model (BFS-01) |
Automatic Vertical (VFFS) Model (BFS-02) |
Automatic Horizontal (HFFS) Model (BFS-03) |
Customizable Options |
|---|---|---|---|---|
|
Packaging Speed |
10-40 bags/min (varies by bag size & material) |
30-120 bags/min (varies by bag size & material) |
20-80 bags/min (varies by bag size & material) |
Up to 180 bags/min for high-speed production lines |
|
Filling Range |
10g-5kg |
5g-2kg |
100g-25kg |
1g-50kg for bulk packaging; 10ml-5L for liquid products |
|
Metering Accuracy |
±1.0% |
±0.5% |
±0.2% |
±0.1% for high-precision pharmaceutical/ food applications |
|
Applicable Material Type |
Granular, powdered, liquid, paste (low viscosity) |
Granular, powdered, liquid, paste, small solid pieces |
All material types, including irregular solids, high-viscosity paste, and mixed materials |
Corrosive materials (chemicals) with 316 stainless steel configuration |
|
Applicable Bag Type |
Pre-made bags (three-side seal, four-side seal, stand-up bags) |
On-site formed bags (pillow bags, gusseted bags) from roll film |
Pre-made bags (stand-up bags, zip-lock bags, doypack, large bulk bags) |
Custom bag types (e.g., vacuum bags, nitrogen-filled bags) |
|
Film/Bag Size |
Bag: 80×60mm-300×200mm |
Film width: Max 720mm; Bag: 80×60mm-350×250mm |
Bag: 150×100mm-600×400mm |
Custom size (film width up to 1200mm; bag up to 1000×580mm) |
|
Sealing Type |
Heat sealing (vertical/horizontal) |
Heat sealing (longitudinal + transverse) |
Heat sealing, ultrasonic sealing (optional) |
Vacuum sealing, nitrogen filling + sealing, hermetic sealing |
|
Sealing Temperature Range |
100-200℃ (adjustable) |
100-300℃ (adjustable, ±10℃ error) |
100-250℃ (adjustable) |
80-300℃ for special film materials |
|
Power Supply |
220V, 50/60Hz, single phase |
220V/380V, 50/60Hz, 3-phase |
380V, 50/60Hz, 3-phase |
Custom voltage for global markets (110V/220V/380V) |
|
Power Consumption |
1.5-2.5KW |
2-4KW |
5-10KW |
15-20KW for high-speed/bulk models |
|
Machine Dimension (L×W×H) |
1000×800×1500mm |
1488×1080×1490mm (standard) |
2000×1500×1800mm |
Compact design for small workshops; customized size for production lines |
|
Machine Weight |
300kg |
680-750kg |
1000-1500kg |
Custom weight based on capacity & configuration |
|
Control System |
Pneumatic electronic control (optional touch screen) |
PLC touch screen control (Siemens/Mitsubishi) + servo control |
PLC touch screen control + servo control |
Imported servo control system; MES system integration option |
|
Warranty Period |
12 months |
12 months |
12 months |
Extended warranty up to 24 months |
|
Material of Contact Parts |
304 stainless steel |
304 stainless steel (food-grade) |
304/316 stainless steel (food-grade/pharmaceutical-grade) |
Food-grade 316 stainless steel for high-hygiene requirements |
|
Additional Functions |
Date coding, photoelectric positioning |
Date coding, UV sterilization, film tension control |
Date coding, vacuum/nitrogen filling, weight detection, bad product rejection |
CIP cleaning, multi-lane packaging, remote technical assistance |
Core Advantages
High-Efficiency Packaging & Large Throughput
With a packaging speed of 10-120 bags/min (upgradable to 180 bags/min), the machine is 10-20 times faster than manual packaging, significantly reducing production time and increasing throughput. The fully automatic models enable 24/7 continuous operation, eliminating production bottlenecks and meeting the high-volume needs of food, agricultural, and chemical industries. The VFFS model, in particular, achieves seamless form-fill-seal operation, further enhancing efficiency by eliminating manual bag handling.
High-Precision Metering & Minimal Waste
Equipped with advanced metering systems (screw, piston, multi-head weigher) and high-precision sensors, the machine achieves metering accuracy of ±0.2% to ±1.0%, ensuring each bag is filled with the exact weight/volume-eliminating underfilling (which leads to customer complaints) and overfilling (which wastes raw materials). The photoelectric positioning system also reduces film/bag waste by up to 40% compared to traditional machines, directly cutting raw material costs. The metering accuracy meets industry standards.
Secure, Leak-Proof Sealing & Product Safety
The machine adopts intelligent PID temperature control and pressure-adjustable sealing technology, ensuring a tight, smooth seal with clear texture-no scorching, tearing, or leakage. The sealed bags meet industry heat seal strength requirements, withstanding vibration, temperature changes, and stacking during transportation and storage, extending product shelf life and ensuring product safety. For food, beverage, and pharmaceutical products, the 304/316 stainless steel contact parts and hygienic design prevent cross-contamination, complying with GMP and FDA standards.
Easy to Operate & Stable Performance
The intuitive PLC touch screen control panel allows operators to set parameters easily, with no professional training required. The system stores hundreds of product recipes, enabling quick switching between different products. The machine uses world-renowned components (Siemens/Mitsubishi PLC, servo motors, Keyence photoelectric sensors), ensuring stable operation with a failure rate of less than 1% per year and a service life of 8-10 years. Multiple safety protection functions (over-temperature, overload, emergency stop, leakage protection) prevent equipment damage and ensure operator safety, with a working noise of ≤80 dB(A) to meet industry standards.
why choose us
Professional Design for Bag Filling & Sealing:
Unlike generic packaging machines, our Bag Filling and Sealing Packaging Machine is specifically engineered to handle the unique characteristics of different materials and bag types-anti-dripping (for liquids), anti-dust (for powders), and leak-proof sealing designs solve the common pain points of bag packaging. We integrate industry standards (JB/T 7549.4-94) into every design detail, ensuring the machine meets global quality requirements and delivers reliable performance for diverse packaging scenarios.
Fully Customizable Solutions:
We understand that every business has unique packaging needs. Whether you need a compact semi-automatic machine for small-batch sachet packaging, we can customize parameters (packaging speed, filling range, bag size, control system) to fit your workshop space and production requirements. We also offer formula customization services, helping you optimize packaging parameters for your specific materials and bag types.
Global Compatibility & Comprehensive After-Sales Support:
The machine supports universal voltage (110V/220V/380V) and complies with CE, FDA, and other global certifications, making it suitable for export to any country. We provide 24/7 online technical guidance, fast spare parts supply, and on-site installation, debugging, and maintenance services (available in most regions). Our 12-month warranty (extendable to 24 months) ensures you have no worries about after-sales issues, and we offer one-to-one technical training to help your staff master the machine operation quickly. We also provide remote technical assistance to resolve issues without on-site visits, minimizing downtime.
