Beverage Straw Extruder
Beverage straw extruder
Two-color beverage straw extrusion
Introduction
Two-color beverage straw extrusion unit consists of extruder
Die, cooling and setting device, traction and cutting device, tube management and conveying device (optional), which can realize single-color extrusion and two-color co-extrusion. The diameter screw designed with brand-new BM separation parameters: the length-diameter ratio is 28: 1, which has good plasticizing effect, large extrusion volume and stable glue output; It is a professional equipment for producing all kinds of drinking straws. By changing some parts, it can produce precision small-sized pipes and small special pipes.
Application Area
Food industry and Other industries
1. Food industry: drink straws, sugar sticks, coffee sticks and oral liquid straws.
2. Other industries: signature refill, nozzle tube, balloon rod, small flagpole, cotton swab rod, medical tube.
Technical Features
The mold is convenient and quick to replace;
The cooling water tank and the water tank rack are all made of stainless steel, which will never rust;
Vacuum sizing is an assembled structure, which can be added at any time; The sink can be adjusted and locked up and down, back and forth, left and right;
There are many combinations of traction cutting devices to meet the production requirements of different products;
The table top and protective cover are made of stainless steel, which is beautiful and generous;
The tube arranging and conveying device can be customized, which is suitable for mass production of various flat-ended tubes.
Technical Parameter
|
Model |
ML12 |
|
|
Feature |
Material |
PP |
|
Color |
2 |
|
|
Straw diameter |
φ3.0 ～ φ12 mm |
|
|
thickness |
0.10 ～ 0.35 mm |
|
|
Straw length |
80 ～ 300 mm |
|
|
Stripes |
Straight or /Helical |
|
|
Capability |
400 ～ 1800 pcs/min |
|
|
Extruding output range |
20 ～40 kgs/hr |
|
|
Extruder |
Main Screw diameter |
φ50 mm ( BM Screw) |
|
Screw L/D |
28 : 1 |
|
|
Main driving motor |
11 Kw (VFD) |
|
|
Vice screw diameter |
φ25 mm×1 |
|
|
Vice driving motor |
0.75Kw ×1(VFD) |
|
|
Gearbox |
ZLY133 |
|
|
Automatic thermo-controller |
8 sets |
|
|
Heating power |
11.63 kw |
|
|
Water cooling tank |
Forming device |
1 set |
|
Vacuum Pump motor |
1.1 kw(choose) |
|
|
Water storage tank |
(length)3400 mm /304 Steel stainless |
|
|
Base frame material |
(304 Steel stainless) |
|
|
Blow dry device |
1 set |
|
|
Take up & Cutting Unit |
Take up unit |
1 set |
|
motor |
0.75kW×1 |
|
|
Cutting knife unit |
1 set |
|
|
motor |
0.75kW×1 |
|
|
angle of port |
90°/60°/45° |
|
|
Digital counter |
1 set |
|
|
Others |
Air compressor |
1.5kw |
|
Dimension LxWxH |
8m×1.2m×1.6 m |
|
|
Machine Weight |
2100 kgs |
|
